MAX485 TTL-485 CONVERTER
Connect a 5 V UART to an RS-485 bus.
Use a MAX485 module to translate logic-level serial signals into an RS-485 physical interface. Integrate it into your host application with appropriate direction control and bus wiring.
Before you order: Check the physical interface, power and signal levels for your host. Match the communication settings at both ends.
Features
| Input voltage | 5V |
|---|---|
| IC | MAX485 |
| Size | 44x14mm |
Pinout & connections
| Pin | Name | Description |
|---|---|---|
| 1 | DE | Send Enable |
| 2 | RE | Read Enable |
| 3 | DI | RX |
| 4 | RO | TX |
| 5 | GND | Ground |
| 6 | VCC | 5V |
| 7 | A | 485A |
| 8 | B | 485B |
Frequently asked questions
Does the connector guarantee host compatibility?
Check the signal standard, logic levels, firmware or driver and communication settings. Matching physical connectors alone is not sufficient.
Documentation & downloads
Bulk orders & project enquiries
Need multiple units or a specific configuration? Send your quantity, project requirements and target delivery date so we can review your request.
Discuss your requirementsFor order questions, email info@longan-labs.cc. For technical support, email support@longan-labs.cc.
