MOS SWITCH DRIVER
Switch a DC load from a controller.
Control a suitable DC motor, LED strip or other load through a MOS switch module. Separate the controller interface from the load supply and check the load's operating and startup current.
Before you order: Check the motor or load voltage, startup current and control interface. Use a driver and supply suited to your load.
Features
| Input voltage | 3.3/5V |
|---|---|
| Output voltage | 0-24V |
| Output current | 5A max; allow for the thermal limits of the assembled module. |
| Size | 33x24mm |
Pinout & connections
| SIG | Control input, HIGH on and LOW off |
|---|---|
| VCC | 3.3/5V |
| GND | Ground |
| VIN | Voltage input of load, 0-24V |
| V+ | Voltage output + |
| V- | Voltage output - |
Frequently asked questions
Can the controller power the load directly?
Use the control connection to command the module and provide a suitable load supply. Check startup current and the driver thermal limits.
Bulk orders & project enquiries
Need multiple units or a specific configuration? Send your quantity, project requirements and target delivery date so we can review your request.
Discuss your requirementsFor order questions, email info@longan-labs.cc. For technical support, email support@longan-labs.cc.
