NRF24L01 2.4G DIGITAL TRANSCEIVER
Add a 2.4 GHz SPI radio to a controller.
Develop a wireless data link with an NRF24L01 transceiver module and onboard antenna. Connect it over SPI and use matching radio settings on the transmitting and receiving devices.
Before you order: Check the physical interface, power and signal levels for your host. Match the communication settings at both ends.
Features
- On-board 2.4GHz antenna
- Low power consumption
| Input voltage | 1.9~3.6V |
|---|---|
| Speed | 2Mbps |
| Communication | SPI |
| Size | 29x15mm |
Pinout & connections
| Pin | Name | Desicription |
|---|---|---|
| 1 | GND | Ground |
| 2 | VCC | 1.9~3.6V |
| 3 | CE | Working mode |
| 4 | CSN | Enable, Active LOW |
| 5 | SCK | Clock of SPI |
| 6 | MOSI | MOSI of SPI |
| 7 | MISO | MISO of SPI |
| 8 | IRQ | Interrupt |
Frequently asked questions
Does the connector guarantee host compatibility?
Check the signal standard, logic levels, firmware or driver and communication settings. Matching physical connectors alone is not sufficient.
Documentation & downloads
Bulk orders & project enquiries
Need multiple units or a specific configuration? Send your quantity, project requirements and target delivery date so we can review your request.
Discuss your requirementsFor order questions, email info@longan-labs.cc. For technical support, email support@longan-labs.cc.
