ADXL345 ACCELERATION SENSOR
Measure acceleration on three axes.
Read an ADXL345 accelerometer through I2C or SPI for movement and orientation-related projects. Select the measurement range required by your application, up to ±16 g.
Before you order: Match power, signal levels and the connector pinout to your host before connecting the module.
Features
- 3 axis sensing
- High sensitivity
- Low power 0.1 μA in standby mode at VS = 2.5 V (typical)
- 10,000 g shock survival
| Input Voltage | 3.3/5V |
|---|
Pinout & connections
- SDO:
| GND | Ground |
|---|---|
| VCC | 3.3/5V |
| CS | Chip select, Low active |
| INT1 | Interrupt output 1 |
| INT2 | Interrupt output 2 |
| SDA | SDA of I2C |
| SCL | SCL of I2C |
Application ideas
- Vibration sensor
- Game controller input
- Robotics
- Smart vehicles
Getting started
- Confirm the power, ground and signal pinout.
- Connect to a suitable input or bus on your controller.
- Read a basic sample and check its response in the intended environment.
Frequently asked questions
Can I use the reading directly in my application?
Check the response with your host and the conditions where it will be used. Analog signals and threshold outputs require different processing from digital measurements.
Documentation & downloads
Bulk orders & project enquiries
Need multiple units or a specific configuration? Send your quantity, project requirements and target delivery date so we can review your request.
Discuss your requirementsFor order questions, email info@longan-labs.cc. For technical support, email support@longan-labs.cc.
