TWO-WAY RELAY 5V
Add two relay-controlled outputs.
Switch two separate loads through a 5 V relay module with status LEDs. Select the trigger arrangement for your controller and check each load against the contact ratings.
Before you order: Coil supply, control-input voltage and contact rating describe different parts of a relay module. Match all three to your circuit and load.
Features
- Jumper to sent HIGH or LOW active
- LED indicator
- Optocoupler isolation
| Operating voltage | 5V (I/O input) |
|---|---|
| Relay working current | 10A@250VAC, 10A@30VDC |
Pinout & connections
DC+: 5V input
DC-: Ground
IN1: INPUT of Relay1
IN2: INPUT of Relay2
NO1: Normal open of relay1
COM1: COM of relay1
NC1: Normal connected of relay1
NO2: Normal open of relay2
COM2: COM of relay2
NC1: Normal connected of relay2
Frequently asked questions
Is the contact rating the required supply voltage?
No. The coil supply powers the relay, the control input triggers it, and the contact rating applies to the switched load.
Bulk orders & project enquiries
Need multiple units or a specific configuration? Send your quantity, project requirements and target delivery date so we can review your request.
Discuss your requirementsFor order questions, email info@longan-labs.cc. For technical support, email support@longan-labs.cc.
