MINI-360 DC-DC ADJUSTABLE STEP-DOWN CONVERTER
Adjust a compact step-down power supply.
Use a Mini-360 buck-converter module to reduce a higher DC supply to the voltage required by your circuit. Adjust and measure the output before connecting the load.
Before you order: This is a power-conversion module. Set and measure the output before connecting a load, and allow for current and thermal limits.
Features
| Input voltage | 4.75~23V |
|---|---|
| Output voltage | 1.0~17V |
| Output current | 3A(Max), 1.8A(Normal); allow for the thermal limits of the assembled module. |
| Conversion efficiency | 96% |
| Switch freq | 340KHz |
| Working temperature | -40℃~85℃ |
| Size | 17x11x3.8mm |
Pinout & connections
Getting started
- Verify input polarity and connect a suitable DC source.
- Set or confirm the output voltage using a meter.
- Connect the load and check voltage and temperature under the expected current.
Frequently asked questions
Can I use the maximum listed current continuously?
Available continuous current depends on the input/output voltage, cooling and load. Check temperature and output stability under the expected operating conditions.
Documentation & downloads
Bulk orders & project enquiries
Need multiple units or a specific configuration? Send your quantity, project requirements and target delivery date so we can review your request.
Discuss your requirementsFor order questions, email info@longan-labs.cc. For technical support, email support@longan-labs.cc.
