4-WAY 24V RELAY
Switch four loads through relay outputs.
Add four relay-controlled outputs to a controller project. Check the module's coil-supply voltage and control-input arrangement before connecting power or a load.
Before you order: Confirm the fitted relay coil voltage and control-input levels with us before powering the module.
Features
- Jumper to sent HIGH or LOW active
- LED indicator
- Optocoupler isolation
| Relay working current | 10A@250VAC, 10A@30VDC |
|---|
Pinout & connections
DC+: 5V input
DC-: Ground
IN1-4: INPUT of Relay 1-4
NO1-4: Normal open of relay 1-4
COM1-4: COM of relay 1-4
NC1-4: Normal connected of relay 1-4
Frequently asked questions
Is the contact rating the required supply voltage?
No. The coil supply powers the relay, the control input triggers it, and the contact rating applies to the switched load.
Bulk orders & project enquiries
Need multiple units or a specific configuration? Send your quantity, project requirements and target delivery date so we can review your request.
Discuss your requirementsFor order questions, email info@longan-labs.cc. For technical support, email support@longan-labs.cc.
