LM2596S DC-DC ADJUSTABLE STEP-DOWN CONVERTOR 3A 12V/24V-12/5V/3.3V
Adjust a DC supply with an LM2596S module.
Use an LM2596S buck converter to reduce a higher DC input to your circuit's required voltage. Set and measure the output before connecting your electronics.
Before you order: This is a power-conversion module. Set and measure the output before connecting a load, and allow for current and thermal limits.
Features
| Input voltage | 3.2~40V |
|---|---|
| Output voltage | 1.25~35V |
| Output current | 3A; allow for the thermal limits of the assembled module. |
| Efficiency rate | 92% |
| Switch frequency | 150KHz |
| Size | 43x21x14mm |
How to Use
- Connect to power at voltage 4~35V.
- Rotate the blue potentiometer knob (clockwise step-up, counterclockwise step-down).
- Check the voltage with multimeter, until the data reaches the target number.
NOTE: The input voltage should be 1.5V or more larger than the output voltage.
Getting started
- Verify input polarity and connect a suitable DC source.
- Set or confirm the output voltage using a meter.
- Connect the load and check voltage and temperature under the expected current.
Frequently asked questions
Can I use the maximum listed current continuously?
Available continuous current depends on the input/output voltage, cooling and load. Check temperature and output stability under the expected operating conditions.
Bulk orders & project enquiries
Need multiple units or a specific configuration? Send your quantity, project requirements and target delivery date so we can review your request.
Discuss your requirementsFor order questions, email info@longan-labs.cc. For technical support, email support@longan-labs.cc.
